Nasir Aluminium manufactures and distributes Aluminium 6061 Angles in Kuala Lumpur, Malaysia, providing a high-strength, versatile alloy for structural and engineering use. Aluminium 6061 has superior mechanical properties, corrosion resistance, and good machinability. Our 6061 angles come in different dimensions to suit construction, automotive, aerospace, and marine applications. The heat-treatable alloy has a superior strength-to-weight ratio and excellent weldability. At Nasir Aluminium, all 6061 angles are produced to close tolerance, ensuring reliability, durability, and predictable performance under a wide range of operating conditions, making it a reliable solution for critical load-bearing and structural applications.
Aluminium 6061 has magnesium (0.8–1.2%), silicon (0.4–0.8%), copper (0.15–0.4%), chromium (0.04–0.35%), and trace elements. In the T6 temper, it has tensile strength of 290–350 MPa, yield strength of 240–300 MPa, and Brinell hardness of approximately 95 HB. It is heat-treatable, possessing high strength along with good fatigue resistance, and excellent corrosion resistance in atmospheric as well as marine environments. It provides good weldability and machinability as well.
Standards : ASTM B221 / B211 ASME SB221 / SB211, EN573, EN485, AMS 4003, AMS 4102
Temper : O,H12,H14,H16,H18,H19,H22,H24
Standard : ASTM, ASME, AMS, GB/T, JIS
Thickness : 50 mm to 6000 mm Long
Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Length : 1 To 6 Meters, Custom Cut Length
Finish : Mill, Customer specific finish
Surface : Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
| Mn | Si | Cr | Cu | Fe | Zn | Al | Mg | Ti | Other Each/Total |
| 0.15 | 0.4-0.8 | 0.15-0.35 | 0.15-0.4 | 0.7 | 0.25 | Remainder | 0.8-1.2 | 0.15 | 0.005/0.15 |
| Tensile Strengtd (PSI) | Yield Strengtd (PSI) | Shear Strengtd (PSI) | Elongation in 2″ | Brinell Hardness |
| 45,000 | 40,000 | 31,000 | 12 | 95 |
| UNS | DIN | USA | WNR |
| A96061 | AlMgSiCu | AA6061 | 3.3211 |
Nasir Aluminium based in Kuala lumpur, Malaysia is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 6061 Angles to meet specific project needs. Our team at Nasir Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@nasiraluminium.com
Aluminium 6061 Angles are applied in construction to frameworks, bridges, and structural supports because they are strong and corrosion-resistant. They are utilized in transportation for truck frames, ship masts, and aerospace parts. They are also well-liked in platform fabrication, walkways, and frames for industrial equipment. The maritime industry prefers them for hull structures and docking reinforcements. In manufacturing, they are employed for machine parts, molds, and jigs. Their strength, light weight, and versatility qualify them for both indoor and outdoor building construction projects.
